Pylontech UP2500 24V 2.84kWh LiFePO4 Battery

Description

The UP2500 is Pylontech’s 24V, 2.8kWh rack-mount lithium battery, ideal for use in battery backup systems for network and telecom security applications, as well as any system requiring 24V DC power, such as mobile RV applications. A single 24V battery is a superior option for balancing and cabling rather than creating a 24V bank from 12V batteries. The UP2500 is ideally sized for many existing 24V systems, while its ability to scale means it can adapt to a wide variety of system sizes.

The combination of Pylontech lithium batteries and Victron inverters has been tested and certified by both Victron and Pylontech R&D departments. The US5000 communicates with the Cerbo GX via the BMS type A cable. This allows the battery bank to share real-time battery health and performance data with the rest of the system, ensuring that the batteries stay  balanced and properly charged.

Pylontech UP2500 Key Features

• Advanced BMS monitors and protects from over-charge/discharge, excess current, and high/low temperatures while managing the allow-to-charge/discharge state, balance, and voltage of each individual cell.
• CAN bus protocol for closed-loop communication.
• Seamless integration with Victron GX devices.
• Long life span, offering up to 6,000 cycles at 90% depth of discharge.
• Stack up to 20 units in parallel for 56.8kWh.
• Backward compatible; upgrade capacity in the future by simply adding new modules to an existing bank.
• Native 24V for easy mobile usage.
• Integral mounting tabs ensure compatibility with standard 19″ server racks.

Pylontech UP2500 Specifications

• Nominal Voltage (vdc): 25.6
• Discharge Voltage (vdc): 23.2 – 28.5
• Charge Voltage (vdc): 28.2 – 28.5
• Nominal Capacity (Wh): 2840
• Depth of Discharge: 90%
• Usable Capacity (Wh): 2550
• Short Current/Duration: <2000A/1ms
• Single String Quantity (pcs): 20
• Humidity: 5%-95%
• Altitude: <6,562′
• Design Life: 10+Years @ 77°F
• Cycle Life: >6,000 @ 77°F
• Dimensions: (w/d/h) 17.4 “x 16.14″ x 4.72”
• Weight: 60.6lb
• Certification: IEC62619/ CE/ RoHS/ UN38.3

Pylontech UP2500 Charge/Discharge Current (A)

• Recommended: 55
• Max. Continuous: 85
• Peak: 100@15sec
