Pylontech LV-Hub Low Voltage Hub

Description

The Pylontech Low Voltage Hub (LV-HUB) is required when more than two battery banks are present, acting as a communications control unit for the parallel connection of a maximum of 5 Pylontech battery groups (maximum 8 modules per group). Can be used with Pylontech Up2500 and US5000 battery units.

Specifications

• Operating voltage range: 48 Vdc
• Communication Interface: CAN/RS485
• System Consumption: 2W
• Size: 442*190*44mm
• Protection Degree: IP20
• Weight: 3.0kg
• Operation Life: 15 years
• Working Temperature: -20~60℃
• Storage Temperature: -40~80℃
• CAN (Max 25 Groups) Baud Rate: 500K; terminal resistance: 0/120Ω
• RS485 (Max 5 Groups) Baud Rate: 9600/115200
