Fortress Power Envy 10kW Whole Home Solar Storage Inverter

Description

The Fortress Power Envy 10kW is a whole-home, all-in-one inverter solution. Paired with the Fortress Power eFlex 5.4 kWh, the eVault MAX 18.5 kWh or LFP-10 MAX batteries, the Envy  features a 60A AC passthrough providing up to 10kw (41.6A @240V) of whole-home backup power. The Envy features a built-in generator input with AC/DC coupling, on- and off-grid capabilities, plus a 2 MPPT output allowing for a maximum of 15 kW PV array. The Envy is equipped with a built-in APsmart Module Level Rapid Shutdown Transmitter and Button, along with integrated AC & DC breakers allowing for fast installation and commissioning.

INPUT DC (PV SIDE)

Max. DC Input Power for Single MPPT: 6000W / 6000 W
Max. PV Input Power: 15000W
Max. PV Power Delivered to Battery & AC Outputs: 12000W
DC Input Voltage Range: 100V-600V
Nominal DC Input Voltage: 360V
Full Power MPPT Voltage Range: 210V-500V
Max. DC Input Current: 25A / 25A
MPPT Number/(Strings per MPPT): 2 / 2

OUTPUT/INPUT AC (GRID)

Continuous AC Power to Grid: 10000W (240V)
Continuous AC Power to Load with Grid or Generator: 14,400W (240V) AC Passthrough/ 12000W GEN
Nominal Output Voltage: 120V/240V
Max. Continuous AC Current: 41.6A @ 240V
Nominal AC Frequency: 50Hz/60Hz

OUTPUT AC (OFF-GRID)

Max. Output Power: 10000W
Nominal Output Voltage: 120V/240V
Nominal Output Frequency: 50Hz/60Hz
Nominal Output Current: 41.6A @ 240V
Peak Power: 20kW / 500ms
Switching Time: Seamless
Dedicated Auto-start Generator Port: 50A / 12kW

BATTERY PARAMETERS

Compatible Battery Type: eVault Max, eFlex, LFP-10 MAX
Nominal Battery Voltage: 48V
Battery Voltage Range: 48V-56V
Maximum Charging/Discharging Current: 210A
Maximum Charging/Discharging Power: 10000W

EFFICIENCY

MPPT Efficiency: 99.9%
Max. Efficiency: 97.5%
CEC Efficiency: 96.5%

PROTECTION

Anti-islanding Protection: YES
DC Switch: YES
Ingress Protect Degree: NEMA 4X, IP65
SPD Protection: YES
AFCI: YES
RSD: Built-in APsmart Transmitter

GENERAL DATA

Dimensions: 580 x 490 x 265mm (22.8 x 19.3 x 10.4 in)
Weight: 44kg (97lbs)
Display: Color LCD
Ambient Temperature Range: -25 to 60 °C (-13 to 140 °F)
Cooling: FAN
Communication: RS485/Wi-Fi/CAN

STANDARD & CERTIFICATION

Certifications: UL1741, UL1741SB, IEEE1547A, rule 21, ISO-NE, FCC15 class B, HECO, CEC, Luma, SGIP, NOM
Warranty: 10 Years / Lead Acid or Fortress Lithium Batteries, other 48v battery manufacturers**
