Xantrex 804-2430 Truecharge2 30A 24V Battery Charger
Xantrex 804-2430 Truecharge2 30A 24V Battery Charger

Xantrex 804-2430 Truecharge2 30A 24V Battery Charger

Original price was: $595.00.Current price is: $536.25.

-

Availability: Out of stock SKU: 804-2430 Category: Tag:

Description


Xantrex Part Number: 804-2430

10, 20 & 30 Amp – 90-265 Vac / 47-63 Hz

AMP-IT-UP! NEW 24-Volt Universal Chargers

Building on the success of the TRUECharge™2 12-volt battery chargers, Xantrex™ now offers 24-volt battery chargers designed to meet the specific needs of marine and commercial markets. Available in 10A, 20A and 30A versions, each model packs a powerful universal charger (90-240Vac, 47-63 Hz) in an ultra-compact, lightweight package.

TRUECharge2 battery chargers are highly versatile and can be mounted in multiple positions, thanks to their inherent drip-free design characteristics. TRUECharge2 delivers outstanding low electrical interference, coupled with efficient, power factor corrected, multistage charging capability. Installation is a breeze, thanks to the easy-access AC and DC wiring compartments. The easy-to-read display can be augmented with an optional remote panel.

NEW PARALLEL FEATURE


TRUECharge2 24-volt chargers are available with parallel stacking feature which allows you to double the output current when used with the optional REMOTE PANEL (part #808-8040-01).

Performance Features:

  • 24-volt models available in 10A, 20A and 30A
  • Microprocessor-controlled, multistage charging algorithms
  • Settings for two and three-stage charging
  • Settings for flooded, gel, AGM or lead-calcium batteries
  • Auto-ranging universal input voltage (90-265 Vac, 47-63 Hz) is also compatible with a generator or other low-quality power sources
  • Power factor corrected, temperature-compensated charging
  • Battery-equalization feature
  • Ability to charge batteries drained to extremely low voltage
  • Battery temperature sensor available (Part #808-0232-01)
  • Optional remote panel (#808-8040-01) required for parallel stacking

    • Protection Features:

  • Reverse battery polarity protection
  • Drip-proof design
  • Over and under-temperature protection
  • DC over-voltage protection
  • Battery overcharging protection

    • Additional information

    taxable

    t

    availability

    Usually ships the same business day

    tab2-content

    Additional Resources: Xantrex Truecharge2 30A 24V Battery Charger – Datasheet Xantrex Truecharge2 30A 24V Battery Charger – Owners Guide
