Sunny Boy 7000 Watt Grid-Tie Power Inverter SB7000TL-US


Sunny Boy 7000 Watt Grid-Tie Power Inverter SB7000TL-US

$3,149.00 $2,849.00


Availability: Out of stock SKU: SB7000TLUS-12 Categories: ,


Transformerless design, maximum yields
The new Sunny Boy TL-US series is UL-listed for North America and features SMA’s innovative H5 topology, resulting in superior efficiencies of up to 98 percent and unmatched solar yields. The transformerless design reduces weight, increases the speed of payback and provides optimum value for any decentralized, commercial PV system. The Sunny Boy TL-US series for North America is the ideal choice for mid-size and large plants from 24 kWp up to the megawatt range.



  • First transformerless SMA inverter to be certified in accordance with UL 1741
  • Optional integrated AFCI functionality meets the requirements of NEC 2011 690.11



  • Maximum efficiency of 98.7%
  • Class-leading CEC efficiency of 98.5%
  • Superior MPP tracking with OptiTrac™
  • Transformerless, with H5 topology



  • OptiCool™ active temperature management



  • Integrated DC disconnect
  • SMA Power Balancer for three-phase grid connection


Assembled in the USA

  • Compliant with ARRA “Buy American” clause


Additional information

Weight 78 lbs

10 Year Standard, 5 & 10 Year Extended Available
