Sunny Boy 2500 Watt High Frequency Inverter with DC Disconnect

Description

The new Sunny Boy high frequency inverters are designed for projects requiring UL certification and represent the next step in innovative SMA technology. Featuring world-class efficiency, a slim-line enclosure and reduced weight, the Sunny Boy HF series of inverters can be mounted in between wall studs, making it perfect for new construction or space-constrained retrofits. Installation is made simple by automatic grid detection*, field configuration for positive ground modules and a wide input voltage range of 175 to 600 V, which provides exceptional system design flexibility. The modern graphic display and wireless Bluetooth communication system provides a wealth of data in a user-friendly format.

Part Number: Sunny Boy 2500HF-US

Features:

• Maximum efficiency 97.3%
• The best tracking efficiency with OptiTrac MPP tracking
• OptiCool™ active temperature management
• Galvanic isolation
• Integrated DC switch-disconnect
• Slim enclosure mounts in between wall studs
• Plug-in grounding with GFDI
• Reduced weight
• Quick and easy configuration thanks to Quick Module
• Modern graphic display
• Bluetooth® technology
• Assembled in the USA
• Compliant with ARRA “Buy American” clause

Input (DC) Specifications:

• Max. recommended PV power (@ module STC): 3125 Watt
• Max. DC power (@ cos = 1): 2750 Watt
• Max. DC voltage: 600V
• DC nominal voltage: 480V
• MPP voltage range: 220 – 480V
• Min. DC voltage / start voltage: 220V / 220V
• Max. input current / per string: 15A / 15A
• Number of MPP trackers: 1
• Fused strings per MPP tracker: 2 standard, extendable to 3

Output (AC) Specifications:

• AC nominal power: 2500 Watt
• Max. AC apparent power: 2500 VA
• Nominal AC voltage / adjustable: 208V / yes or (240V / yes)
• AC voltage range: 183 – 229V or (211 – 264V)
• AC grid frequency; range: 60 Hz; 59.3 – 60.5 Hz
• Max. output current: 12.0A or (10.4A)
• Power factor (cos): 1
• Phase conductors / connection phases: 1 / 2
• Harmonics: < 4 %

Efficiency:

• Max. efficiency: 96.9%
• CEC efficiency: 96.5%

Protection devices:

• DC reverse-polarity protection: yes
• AC short circuit protection: yes
• Galvanically isolated / all-pole sensitive monitoring unit: yes / —
• Protection class / overvoltage category: I / III

General Data:

• Dimensions (W X H X D): 14 X 29 X 7″
• Weight / DC Disconnect weight: ~51 lb incl. DC Disconnect
• Operating temperature range (full power): –13 – +113°F
• Internal consumption at night:
• Topology: HF transformer
• Cooling concept: OptiCool
• Electronics protection rating / connection area: NEMA 3R / NEMA 3R
• Display: text line / graphic: — / yes
• Interfaces: RS485 / Bluetooth: opt. / yes
• Warranty: 10 / 15 / 20 years: yes / opt. / opt.
• Certificates and permits (more available on request): UL1741, UL1998, IEEE 1547, FCC Part 15 (Class A & B), CSA C.22 No. 107.1-01
