Samlex European 23 Amp Switching Power Supply SEC-1223CE

-10%

Samlex European 23 Amp Switching Power Supply SEC-1223CE

$126.00 $114.00

SKU: SEC-1223CE Category:
  • Description
  • Downloads
  • Additional information

Description

This Samlex SEC-1223CE power supply is a high efficiency AC-DC power converter and provides a highly regulated output DC voltage of 13.8 Volts at 23 Amps with an AC input of 230 Volts, 50 Hz. These advanced switch-mode DC power supplies were designed specifically for use with land mobile radio. The power supplies produce clean reliable power and are highly filtered to suppress RFI. The unit comes with a detachable power supply cord with “SCHUKO” plug. Features include over-current, short-circuit, over-voltage and over-temperature protection. The AC-DC power supply conforms to EN60950 safety standards and EN55022 class B, EN6100-3-2,3 and EN61000-4-2,3,4,5,6,8,11 EMI/EMC standards.



Specifications:

  • Input: 230 VAC, 50Hz
  • Output: 13.8 VDC
  • Amps: 23 Amps
  • Fuse: 6.3 Amps
  • Weight: 4.8 (lbs)
  • Dimensions: 8.19 x 7.28 x 2.4 (in)
  • Safety: RoHS Compliant
  • Warranty: 3 Year Limited



Features:

  • Advanced switch-mode technology
  • Reliable power with minimum weight and size
  • Circuit innovations minimize output voltage ripple and RFI
  • Input voltage 230 VAC

Additional information

Weight 5 lbs
