PowerMax 2000 Watt Pure Sine Wave Inverter PMX-2000



View cart


PowerMax PMX-2000 Overview:

  • PowerMax, who is known in the RV and marine industries for their DC converters, chargers and transfer switches, has now come out with a line of DC to AC pure sine wave power inverters to compliment it’s trusted lineup!
  • The PMX-2000 inverts 12VDC to AC, meets 120V AC electronic appliance safety operating standard and can be used to power most electronic appliances or equipment.
  • This inverter provides a high-efficiency output, powerful starting capability, digital control and pure sine wave output.
  • Features include DC voltage detection, high/low voltage alarm, high/low voltage protection, auto-reset, overload protection, short circuit protection, USB, remote function (on/off by remote). The inverter will shut down if the internal temperature gets too hot and will be automatically reset after the unit cools down.
  • Aluminum housing, 1 year warranty


PowerMax PMX-2000 Specifications:

  • MAX. continuous Output Power: 2000 Watts
  • DC Input Static Current (No Load): ≤ 1.5 Amp
  • AC Output Wave Form: Pure Sine Wave
  • Low Voltage Alarm: 10.5 ± 0.5V
  • Low Voltage Cut Off Level: 10.5V
  • Auto-reset after shut-down: 12 V ±0.5V
  • High Voltage Cut Off Level: 15V-16.5V
  • Output AC Voltage: AC 115V ± 10% RMS
  • Output Frequency Level: 60 ± 1Hz
  • Overload Power Range: 2000 Watts +5-30%
  • USB Power Port Output V/A: DC 4.7-5.3V / 2100mA
  • Full Load Optimum Efficiency: ≥ 85%
  • AC Output Short Circuit Protection: system shut down (no damage)
  • Temperature Protection: < 65°C
  • Cooling Fan: depend on inner temperature rising above ≥ 45°C
  • Led Indicators: normal/Green, fault/Red
  • Dimensions: 13.1 x 8.8 x 3.8
  • Weight: 11.5lbs.

Additional information

Weight11.5 lbs
