Victron Energy Orion XS 12/12-70A DC-DC Battery Charger

Description

New 70A model, the largest Orion XS to date! Available for PREORDER, will sell out quickly!

Using engine power to charge your service battery, the Orion XS DC-DC charger combines impressive power with an ultra-compact, fanless design.

The Orion XS supports any alternator and battery setup with configurable voltage and current, achieving 98.5% efficiency and maintaining full rated output even at 40°C/104°F. It draws a stable load from smart Euro 5/6 alternators, preventing the service battery from being undercharged. The 4-stage charging algorithm adapts to discharge depth, extending battery life across all common chemistries.

Recreational Vehicles
Whether you’re off-grid for an adventurous weekend or a full expedition, the Orion XS keeps your house batteries charged and protected. It works with smart alternators, comes in 12V and 12/24V models, and fits neatly into tight spaces.

Professional Vehicles
Designed by the market leader in ambulance power systems, the Orion XS delivers reliable DC charging for demanding mobile applications. It protects alternators with input current limiting, supports all common battery types, and keeps performing in harsh conditions.

Marine
Tough and compact the Orion XS is made for life onboard. It delivers efficient DC-DC charging in cramped engine compartments, supports multiple battery banks, and offers 12/24V conversion with the XS 1400 model.

Adaptive charge algorithm
The Orion’s smart four-stage charge algorithm extends battery life by adjusting its stages to match shallow or deep discharges. It supports lithium and all common lead-acid chemistries—AGM, Gel, and flooded—via eight presets or fully customizable settings.

Low temperature shutdown & undervoltage protection
To prevent damage to lithium batteries, the charger automatically shuts down at sub-zero temperatures. It also turns off if the input voltage drops below a set threshold, and restarts when voltage recovers, protecting the starter battery from deep discharge.

SafetyShield+ protection: the professional standard
Engineered for critical applications, the Orion XS features IP65 water- and dust protection, temperature-compensated charging, and comprehensive safeguards against overload, short circuits, overcharging, and overheating.
