Dimensions 3000W 12VDC Quasi Sine Inverter Charger

Description

Dimensions Part Number: 12X30B3TU

This Dimensions 12X30B3TU 3000W 12VDC Quasi Sine Inverter Charger is a low frequency design that will efficiently power any load within its wattage rating. Its iron-core transformer can handle the frequent power surges associated with industrial grade tools, pumps, heaters, and motors. These Dimensions inverters are UL listed so you can be confident in our consistent quality.

Specifications:

• Output Power: 3000W
• Peak Watts: 9,600W
• Warranty: 4 Years, Advance Replacement first 2 years
• Output Voltage: 120 VAC
• Output Peak: 90amps
• Output Current: 25amps
• Output Waveform: Quasi Sine
• Output Frequency: 60 Hz
• Motor Starting Capacity: 1 hp
• Input Voltage: 12
• Continuous Output Amps: 25amps
• Operating Temp: -20 to 40 C (0 to 104 F)
• Efficiency: Up to 93%
• Weight: 53 lbs
• Dimensions: 15.75″ x 11.5″ x 7.75″
• UL Certified: No
• Phase: Single
• Topology: Low Frequency
• Input Voltage Range: 11 to 17 VDC

Features:

• Thermally-controlled cooling fan
• GFCI outlet protection
• Enclosed AC and DC cable connections with strain relief
• Remote ON/OFF switch hookup
• LED for Inverter power, Low battery, High temperature, & Overload
• Battery voltage indicator with push-to-test
• Optional Remote Panel R with LED indication of External power, Inverter power, Low battery, Overload, and High temperature
• Optional Remote Panel R4 with Liquid Crystal Display (11 operating & 12 troubleshooting messages)
• Automatic electronic short circuit/overload protection
• Automatic high temperature shutdown
• Output circuit breakers
• Automatic low battery shutdown at 10.5 VDC (with in-rush delay)
• B3 Battery Charger
