COTEK 2000 Watt 48V Pure Sine Inverter SP-2000-148
$667.00
-
- Description
- Downloads
- Accessories
- Additional information
Description
COTEK Part Number: SP-2000-148
Features:
- Pure sine wave output
- Power ON / OFF remote control (Green Terminal)
- Remote controller CR-8 / CR-16 (optional)
- Input & Output fully isolation
- Temperature & Load controlled cooling fan
- Built in advance microprocessor to provide friendly interface
- Output frequency 50 / 60 Hz selectable by DIP switch
- Output voltage DIP switch selectable
- Adjustable power saving mode by variable resister
- 3-color LED status indicators
- Input protection: Reverse Polarity (Fuse) / Under Voltage / Over Voltage
- Output protection: Short Circuit / Overload / Over Temperature
- E-13 / UL / CE / FCC approved
Specifications:
- AC Voltage: 100 / 110 / 115 / 120VAC +/- 5%
- Rated Power: 2000VA
- Surge Power (1 sec): < 3500VA
- Maximum Output Power (1 Min): > 2000VA~2300VA (100%~115%)
- Waveform: Pure sine wave
- Frequency: 50 / 60 Hz +/- .5%
- AC Regulation: +/- 5%
- DC Voltage: 48VDC
- Voltage Range: 42.0V~66.0VDC
- No Load Power Consumption @ Save Mode: < 0.05A@ 48VDC
- No Load Power Consumption @ No Load Mode: < 0.5A @ 24VDC
- Standard Receptacles: GFCI
- Full Load Efficiency: 94%
- Input Under Voltage Protection: 42.0V ±1.0VDC
- Input Under Voltage Alarm: 44.0VDC ±1.0VDC
- Input Under Voltage Recovery: 50.0VDC ±1.0VDC
- Input Over Voltage Protection: 66.0VDC ±1.0VDC
- Input Over Voltage Recover: 58.0VDC ±1.0VDC
- Output Overload: Shutdown output voltage, restart to recovery
- Output Short: Shutdown output voltage, restart to recovery
- DC Input Reverse Polarity: By Fuse
- Operating Temp: -20 ~ +40C
- Storage Temp: -30 ~ +70C
- Storage Temp. Humidity: 10 ~ 95% RH
- Safety Standards: Certified UL 458 (UL only for GFCI receptacles)
- EMC Standards: Certified FCC class B
- Remote Control (Optional): CR-8 / CR-16
- LED Indicator: Input voltage level, output load level and faulty status
- Dry Contact Terminal: By relay
- Remote Control Terminal: 6-port green terminal
- Cooling: Temperature & load controlled cooling fan
- Dimensions (L x W x H): 17.44 x 9.76 x 3.27 in
- Weight: 11.6 lbs
Additional information
| Weight | 11.6 lbs |
|---|---|
| Warranty | 2 Year |
