Aims 1500 Watt 12V Pure Sine Wave Inverter PWRI150012120S

Description

Aims Part Number: PWRI150012S

New and Improved Design!

Specifications:

• Continuous output power: 1500 watts
• Surge power: 3000 watts
• Input voltage range: 9.5-16VDC
• Output voltage: 120VAC
• DC input: 12VDC
• Output wave form: Pure sine wave @ 60Hz (THD < 3%)
• Efficiency: 90%
• USB Output: 5VDC, Max, 1A
• Input over-voltage shutdown: 16 ± 0.5VDC
• Input under-voltage shutdown: 9.5 ± 0.5VDC
• Input under-voltage alarm: 9.8 ± 0.3VDC
• Over temperature protection: 149 ± 8°F
• Over-load protection: 1700W ± 200W
• No Load Consumption: 0.8A
• Working Temperature: 32-104°F
• Storage temperature: 14-113°F
• Intelligent cooling fan: (starts running when the case temperature reaches 104°F)
• Dimensions: (L x W x H) 15.875 x 8.375 x 3.875 in.
• Unit Weight: 10 lbs
• Shipping weight: 12 lbs

Features:

• 1500 watts continuous power
• Can handle a 15 volt DC Input
• Pure sine wave
• USB Port
• Triple ac receptacles
• On/off switch
• Over temperature indicator
• Overload protection
• Low battery voltage warning/shutdown
• High input voltage protection with automatic shutdown
• Over load indicator
• Short circuit protection
• Dual cooling fans thermally controlled
• ac output short circuit protection
• Instruction manual
• Free 1 year tech support
• 1 Year Warranty Parts and Labor
• Remote port for optional remote

REMOTEHF – Flush Mount Remote Switch

4 AWG Cables & Fuses
