COTEK 600 Watt 24V Pure Sine Inverter S600R-124

-10%

COTEK 600 Watt 24V Pure Sine Inverter S600R-124

$345.00 $309.00

  • Description
  • Downloads
  • Additional Information
  • Reviews (0)

Product Description

This high efficiency UL 458 approved microprocessor controlled DC-AC inverter converts 12 Volts DC to 600 watts of pure sine-wave AC power at 100/110/120 Volts, 50/60 Hz. The unit comes with a set of input battery cable lugs and dual NEMA 5-20R GFCI receptacles (other types of output AC sockets may be requested). Features include overload, short circuit, over-temperature, low battery, polarity reverse, under & over voltage protections.



Part Number: COTEK S600R-124



Features:

  • True sine wave output (THD 3% Typ.)
  • Output frequencyF50 / 60Hz switch selectable
  • Input & output fully isolation design
  • Capable of driving highly reactive & capacitive loads at startup
  • Tri-Color indicators display input voltage & output load level
  • Loading controlled cooling fan
  • Advanced microprocessor
  • Input polarity reverse / under voltage / over voltage protections
  • Output short circuit / overload / over temperature
  • UL / e-13 / CE / FCC approved



Specifications:

  • AC Voltage: 100 / 110 / 120VAC
  • Continuous Power: 600W
  • Surge Power: 800W
  • Waveform: True sine wave
  • Frequency: 50 / 60 Hz (Switch Selectable)
  • AC Regulation: +/- 3%
  • Standard Receptacles: NEMA5-15R / GFCI
  • LED Indicator: Input voltage level, output load level and fault status
  • No Load Current Draw: 0.43A
  • DC Voltage: 24VDC
  • Voltage Range: 21.0~30.0VDC
  • Efficiency: 90%
  • Fuse: 20A x 2
  • Cooling: Loading controlled cooling fan
  • Remote Control: By external switch
  • Battery Low Shutdown: 21.0V +/- .5V
  • Over Load: Shut off output voltage, re-power on to recover
  • Over Voltage: 30.6VDC
  • Over Temp: Shut off output voltage, auto resets
  • Output Short: Shut off output voltage, re-power on to recover
  • Battery Polarity Reverse: By Fuse Open
  • Safety Standards: UL458 (only for “GFCI” receptacles)
  • Isolation Resistance: I/P ~ O/P: 100M Ohms / 500VDC
  • EMI Conduction & Radiation: Compliance to FCC class B
  • Dimensions(L x W x H): 11.6 x 7.1 x 2.8 in
  • Weight: 7.5 lbs



Additional Information

Weight 7.5 lbs
Warranty

2 Year
