Aims UL 458 2000 Watt 12V Inverter Charger PICOGLF20W12V120V

-10%

Aims UL 458 2000 Watt 12V Inverter Charger PICOGLF20W12V120V

$739.00 $668.00

  • Description
  • Downloads
  • Accessories
  • Additional Information
  • Reviews (0)

Product Description



The Aims PICOGLF20W12V120V is the UL 458 approved version of the wildly popular PICOGLF20W12V120VR inverter charger. The design is somewhat different to ensure compliance and conform to UL standards.



PICOGLF20W12V120V Features:

  • Listed to UL 458 Standards
  • 2000 watt low frequency inverter
  • 6000 watt surge for 20 seconds -3x surge capability
  • GFCI
  • Battery Priority Selector
  • Terminal Block
  • Marine Coated and Protected
  • Multi Stage Smart charger 35 Amp
  • remote panel available
  • auto frequency
  • auto gen start
  • 10msec typical transfer time
  • 7 battery type settings for charge



Inverter Output Specifications:

  • Listed to UL 458 Standards
  • Continuous Output Power: 2000 Watts
  • Surge Rating: 6000 Watts (20 Seconds)
  • Output Waveform: Pure Sine/Same as input (Bypass Mode)
  • Output Voltage: 100-110-120Vac
  • Nominal Efficiency: >88% (Peak)
  • Line Mode Efficiency: >95%
  • Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
  • Typical Transfer Time: 10ms (Max)
  • THD: < 10% DC



Input Specifications:

  • Nominal Input Voltage: 12.0Vdc
  • Minimum Start Voltage: 10.0Vdc
  • Low Battery Alarm: 10.5Vdc-11.0Vdc
  • Low battery Trip: 10.0Vdc-10.5Vdc
  • High Voltage Alarm: 16.0Vdc
  • Low battery Voltage Restart: 15.5Vdc
  • Idle Consumption: < 3 amps DC
  • Power Saver Mode Idle Consumption: < 2 amps DC depending on search mode



Charger Specifications:

  • Output voltage: Depends on battery Type
  • Charger Rate: 70A





Dimensions:

  • Unit Weight: 47.4 lbs.
  • Unit Size L x W x H: 17.40 x 8.59 x 7.05 inches
  • Shipping Weight: 55 lbs.
  • Shipping L x W x H: 20.5 X 13.8 X 12.2 inches

Additional Information

Weight 47 lbs
Warranty

1 Year
